Deep Cycle 24V 200Ah Lifepo4 Lithium Battery 25.6V 5.12kwh Delong

Delong 24V 200Ah lithium battery utilizes lithium iron phosphate technology, allowing it to operate within a wide temperature range. Coupled with its internal smart BMS, it features a very stable discharge curve and consistent voltage. The BMS also prevents adverse conditions such as overcharging and over-discharging, providing you with a highly stable and safe state.

Nominal Voltage: 25.6V
Nominal Capacity: 200Ah
Battery Energy: 5120Wh
Max Charge Current: 70A
Terminal: M8
Case Material: ABS+PC
Waterproof Level: IP58
Charge Temperature Range: 0~45℃
Discharge Temperature Range: -5~55℃
Cycle Life: ≥6500 Cycles
Dimensions (LxWxH): 522*239*218mm

Inquiry Now
Email us

6500+ Long Lifespan

The Delong 24V 200Ah lithium battery is capable of completing 6,500 cycles and has obtained certifications such as CE, IEC, UN38.3, MSDS, and ROHS. We offer a 10-year after-sales warranty, with professional technicians available to provide guidance. It is a safe, reliable, and environmentally friendly energy solution.

Smaller and Lighter

Compared to traditional lead-acid technology, the Delong 24V 200Ah lithium battery can store more energy, is smaller in size, and lighter in weight. It saves your physical effort and frees up more usable space for your home.

Additionally, the lithium battery has a very low self-discharge rate, with an effective capacity of up to 96%, providing longer power for your devices, an alternative for lead acid, AGM, or batteries. The 24V 200Ah solar battery is ideal for deep cycle applications such as uninterruptible power supplies (UPS), RVs, campers, and trolling motors.

24v 200ah lithium battery Application

24v 200ah lithium battery Application

Support Serie and Parallel, Fast Charging

To meet your power needs, Delong lithium batteries are designed with strong scalability. You can connect 2 packs of 24V 200Ah lithium batteries in series to achieve 48V 200Ah, or connect 4 packs in parallel to reach 24V 800Ah. By DIY connecting them, you can obtain higher voltage or greater capacity to satisfy more power demands. Additionally, Delong 24V 200Ah lfp battery supports three charging methods, with a maximum charging current of 70A, and a charging time of 3-4 hours.

Related Article: Series Vs. Parallel Battery | How To Choose?

Portable Handles

The 24V 200Ah lifepo4 battery is equipped with handles on both sides. Whether it’s for lifting, carrying, or installation, the handles make it very convenient to use. The lithium battery does not contain acid, eliminating the risk of liquid leakage and reducing the need for maintenance. You can also adjust the installation orientation based on your actual situation.

Bluetooth And Self-heating

You can also adjust various battery parameters on your mobile phone using the Bluetooth feature, enhancing your convenience in daily life. If you are in a cold region, you can opt for the self-heating function. This self-heating feature allows the battery to maintain a stable working state even in extremely cold conditions, extending its lifespan.

Customized Service

We provide lithium batteries and customization services for users around the world. You can specify the voltage, current, temperature, functions, BMS, and cell types (LFP, LiPo, or 18650), among others. Delong lithium battery factory in China offers high-quality batteries at competitive prices.

Delong Energy Factory

Delong Energy Factory

Model DL-LFP24200
Product Specification 24V 200Ah
Nominal Voltage 25.6V
Nominal Capacity 200Ah
Battery Energy 5120Wh
Max Charge Current 70A
Charging Cut-off Voltage 28.8V ± 0.2V
Max Discharge Current 200A
Discharging Cut-off Voltage 22.4V ± 0.2V
Cell Type LiFePO4 Battery
Display LCD (Optional)
Terminal M8
Case Material ABS+PC
Waterproof Level IP58
Charge Temperature Range 0~45
Discharge Temperature Range -5~55
Cycle Life ≥6500 Cycles
Designed Life 12 Years
Colour Black
Weight 20Kg
Dimensions (LxWxH) 522*239*218mm
Assembly Method Built In

24V 200Ah Lithium Battery Datasheet – DL-LFP24200

UN38.3, MSDS, KC, CE, CB, IEC, UL, ISO, more info please contact us.

Lithium Battery Certification

FAQ

The nominal voltage of the Delong 24V 200Ah lithium battery is 25.6V, capable of storing 5120Wh of energy.

The maximum charging current of the Delong 24V 200Ah lithium iron phosphate battery is 70A. We recommend charging at a current lower than 70A to help extend the battery’s lifespan.

The Delong 24V 200Ah lithium battery can be used for 12 years and complete 6,500 charge and discharge cycles. If the power of the device is 5kW, then the 24V 200Ah lithium battery can provide power to this device for approximately 1 hour. The higher the power consumption, the shorter the battery’s runtime.

Charging the 24V 200Ah lithium battery with a charging current of 50A will take 4 hours to fully charge.

If you are using a 410W solar panel with an average sunlight duration of 5 hours per day, each panel can produce 2050Wh.

Therefore, 5120Wh ÷ 2050Wh ≈ 2.5 panels.

You will need approximately 3 pieces of 410W solar panels to meet the needs of the 24V 200Ah battery. Please calculate the actual number based on the power of the solar panels, or contact Delong for more accurate recommendations.

The Delong 24V 200Ah lithium battery supports taxes free, and the price is related to the purchase quantity and shipping costs. Please contact us to obtain the shipping costs required to transport to your country from China, such as shipping to India, South Africa, the United States, Australia, Ukraine.
